CIMI4D is a dataset of rock climbing motions recorded using RGB cameras, LiDAR, and IMUs. CIMI4D collects 42 action sequences of 12 actors climbing 13 rock walls, and provides finely annotated human poses and global trajectories (orange lines). Pictures show various types of complex scenes and challenging actions in CIMI4D.


Abstract

Motion capture is a long-standing research problem. Although it has been studied for decades, the majority of research focus on ground-based movements such as walking, sitting, dancing, etc. Off-grounded actions such as climbing are largely overlooked. As an important type of action in sports and firefighting field, the climbing movements is challenging to capture because of its complex back poses, intricate human-scene interactions, and difficult global localization. The research community does not have an in-depth understanding of the climbing action due to the lack of specific datasets. To address this limitation, we collect CIMI4D, a large rock ClImbing MotIon dataset from 12 persons climbing 13 different climbing walls. The dataset consists of around 180,000 frames of pose inertial measurements, LiDAR point clouds, RGB videos, high-precision static point cloud scenes, and reconstructed scene meshes. Moreover, we frame-wise annotate touch rock holds to facilitate a detailed exploration of human-scene interaction. The core of this dataset is a blending optimization process, which corrects for the pose as it drifts and is affected by the magnetic conditions. To evaluate the merit of CIMI4D, we perform four tasks which include human pose estimations (with/without scene constraints), pose prediction, and pose generation. The experimental results demonstrate that CIMI4D presents great challenges to existing methods and enables extensive research opportunities.

Dataset

CIMI4D Overview

Setup

CIMI4D Hardware

Annotation

CIMI4D Pipeline

DataSet Qualitative Evaluation

Benchmark

CIMI4D Benchmark

Tasks

CIMI4D Tasks

Citation

@inproceedings{yan2023cimi4d,
  title={CIMI4D: A Large Multimodal Climbing Motion Dataset under Human-scene Interactions},
  author={Yan, Ming and Wang, Xin and Dai, Yudi and Shen, Siqi and Wen, Chenglu and Xu, Lan and Ma, Yuexin and Wang, Cheng},
  booktitle={Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR)},
  pages={12977--12988},
  month={June},
  year={2023}
}
